TTO T30 Pneumatic Thermal Transfer Overprinter

32 mm print head · 300 DPI · built for high-speed VFFS / HFFS lines.

Print Head32 mm
Resolution300 DPI
Max SpeedUp to 600 mm/s
Ribbon33 mm × 600 m

Prices are not published. Configuration and pricing are provided per inquiry.

The DEMAC T30 pneumatic thermal transfer overprinter uses a 32 mm print head at 300 DPI, designed for high-speed vertical […]

5 Core Technical Advantages

High-speed printing
Pneumatic pulse drive up to 600 mm/s, coding without stopping high-speed lines.
Crisp 300 DPI code
Kyocera head outputs clear QR and small text, high scan rate.
Smart ribbon saving
Auto gap detection and intermittent printing save up to 40% ribbon.
Easy integration
Standard RS232/USB and photocell signals connect to PLC and weighers.
Multi-language UI
Chinese / English / Spanish / Arabic UI for overseas lines.

The DEMAC T30 pneumatic thermal transfer overprinter uses a 32 mm print head at 300 DPI, designed for high-speed vertical (VFFS) and pillow (HFFS) packaging lines. It prints production dates, batch numbers, expiry dates, QR codes and 1D barcodes with high readability. The pneumatic drive delivers stronger impression force, ideal for thick films and laminates.

Full Technical Parameters

Print Area	32 × 60 mm (single), 32 × 120 mm (twin)
Resolution	300 DPI
Ribbon Width	33 / 35 mm
Ribbon Length	600 m
Power	110–220V, 50/60Hz
Air Supply	6 bar clean dry air
Weight	≈ 18 kg

Substrates & Industries

Suitable for online date and barcode coding on flexible pouches of puffed food, frozen food, confectionery, coffee beans, etc.

Applicable Substrates

Typical Industries

OEM / ODM Customization

OEM/ODM supported: private label, housing color, UI language, print-head spec and mechanical interface can be customized to your line.

OEM MOQ from 50 units, lead time 25–35 working days.

FAQ for This Model

Which packaging machines does T30 fit?

VFFS, HFFS and rotary pouch machines; standard mounting brackets provided.

Can third-party ribbon be used?

Compatible with Near-Edge wax / mixed / resin ribbon, 33 mm.

Tell us your substrate and line speed

Our engineer will reply within 1 working day with model advice, print samples and a full quotation.
